Grid Shell Space Frame

Grid shell space frames from Xuzhou Shengjian combine ultra-lightweight steel grids with shell structural efficiency, creating striking glazed roof canopies for atriums, airports, and public buildings. Advanced form-finding analysis ensures optimal geometry. Compatible with glass, ETFE, and polycarbonate cladding. Request a free design consultation.

Technical Advantages

The grid shell space frame combines the efficiency of a structural shell with the fabrication advantages of a steel grid, creating elegant, ultra-lightweight roofs with exceptional spanning capability. Our grid shells are engineered using advanced form-finding analysis to ensure optimal structural geometry under all load conditions. Key features: • Ultra-lightweight — minimal steel mass for maximum architectural span • Perfect for glazed roofs, atriums, and transparent architectural canopies • Form-finding analysis ensures the most efficient structural geometry • Compatible with glass, ETFE film, or polycarbonate cladding systems • Each node is individually positioned to achieve the intended shell form • Used in public buildings, shopping centers, botanical gardens, and airports Xuzhou Shengjian has designed and fabricated grid shell structures for landmark public buildings and transit hubs worldwide. Share your project requirements and architectural concept for a free feasibility review and cost estimate.
